Ramato is Leading Manufacturer and Exporter from INDIA For Welding Machine Like Transformer Based Air Cooled and Oil Cooled Welding, Spot Welding, Arc and MMA Welding, Argon Tig Welding, MAG Co2 Mig Welding, Air Plasma Cutting Machine, Laser Welding and All Type of pneumatics, Hydraulic and Mechanical Welding Machines and All Type of SPM Automatic Machinery with PLC Control, Ac Drives and Machine Tools in Rajkot, Gujarat, INDIA.
Ramato Make ARC Welding Machine | RAMATO | Rajlaxmi Machine Tools Rajkot.
Our Ramato Series SEO-optimized arc welding machines offer superior performance and reliability, allowing you to create strong and clean welds with precision and efficiency.
Perfect for professional welders and DIY enthusiasts alike, our arc welding machines are the ideal choice for a wide range of welding projects.
Upgrade your welding equipment today and experience the difference with our high-quality arc welding machines.
We Have Wider Range of Ramato Series of Single Phase and Three Phase Arc and MMA Series of Model Like 200A, 200DT, 200S, 200E, 200G, MMA-200A, 200i, 250i, 300i, 400i, 250G, 250T, 300G, 315G, 400G, 400ij, 415G
Power source: Arc welding machines require a power source to create an electric arc between the welding electrode and the workpiece. This power source may be a generator, a rectifier, or an inverter.
Controls: Arc welding machines typically have controls that allow the user to adjust parameters such as voltage, amperage, and wire feed speed.
Electrode holder: The electrode holder is a device that holds the welding electrode in place and conducts the electric current to the electrode.
Ground clamp: The ground clamp is used to connect the welding machine to the workpiece, completing the electrical circuit.
Cooling system: Some arc welding machines have a built-in cooling system to prevent overheating during extended use.
Portability: Many arc welding machines are designed to be portable, with handles or wheels for easy transportation.
Duty cycle: The duty cycle of an arc welding machine indicates how long the machine can operate at its maximum output before needing to cool down. This is an important consideration for heavy-duty welding applications.
Digital displays: Some modern arc welding machines come equipped with digital displays that provide real-time feedback on welding parameters, making it easier for the user to monitor and adjust settings as needed.
Construction industry: Portable arc welding machines are commonly used in the construction industry for tasks such as joining metal beams, welding reinforcing bars, and fabricating metal structures.
Shipbuilding industry: Arc welding machines are essential for the shipbuilding industry, where they are used to fabricate hulls, decks, and other components of ships and boats.
Automotive industry: Portable arc welding machines are commonly used in the automotive industry for tasks such as repairing vehicle bodies, welding exhaust systems, and fabricating metal components.
Aerospace industry: Arc welding machines are used in the aerospace industry for tasks such as welding components of aircraft, spacecraft, and other vehicles used in the aerospace sector.
Manufacturing industry: Portable arc welding machines are widely used in the manufacturing industry for tasks such as welding metal components, fabricating machinery, and repairing equipment.
Overall, portable arc welding machines are versatile tools that are used in a wide range of industries for various welding applications.
Features
Power source: Arc welding machines require a power source to create an electric arc between the welding electrode and the workpiece. This power source may be a generator, a rectifier, or an inverter.
Controls: Arc welding machines typically have controls that allow the user to adjust parameters such as voltage, amperage, and wire feed speed.
Electrode holder: The electrode holder is a device that holds the welding electrode in place and conducts the electric current to the electrode.
Ground clamp: The ground clamp is used to connect the welding machine to the workpiece, completing the electrical circuit.
Cooling system: Some arc welding machines have a built-in cooling system to prevent overheating during extended use.
Portability: Many arc welding machines are designed to be portable, with handles or wheels for easy transportation.
Duty cycle: The duty cycle of an arc welding machine indicates how long the machine can operate at its maximum output before needing to cool down. This is an important consideration for heavy-duty welding applications.
Digital displays: Some modern arc welding machines come equipped with digital displays that provide real-time feedback on welding parameters, making it easier for the user to monitor and adjust settings as needed.
Applications
Construction industry: Portable arc welding machines are commonly used in the construction industry for tasks such as joining metal beams, welding reinforcing bars, and fabricating metal structures.
Shipbuilding industry: Arc welding machines are essential for the shipbuilding industry, where they are used to fabricate hulls, decks, and other components of ships and boats.
Automotive industry: Portable arc welding machines are commonly used in the automotive industry for tasks such as repairing vehicle bodies, welding exhaust systems, and fabricating metal components.
Aerospace industry: Arc welding machines are used in the aerospace industry for tasks such as welding components of aircraft, spacecraft, and other vehicles used in the aerospace sector.
Manufacturing industry: Portable arc welding machines are widely used in the manufacturing industry for tasks such as welding metal components, fabricating machinery, and repairing equipment.
Overall, portable arc welding machines are versatile tools that are used in a wide range of industries for various welding applications.
| Model | ARC 200 SG | ARC 250 SG | ARC 300 SG | ARC 300 ZX | ARC 400 ZX | RJ-200A | RJ-250A | RJ-330A |
| Input Voltage (V) | 220 V ± 15% (1 Phase) | 220 V ± 15% (1 Phase) | 220 V ± 15% (1 Phase) | 220-415 V ± 15% (1-2 Phase) | 220-415 V ± 15% (1-2-3 Phase) | 220-415 V ± 15% (1-2 Phase) | 220-415 V ± 15% (1-2 Phase) | 220-415 V ± 15% (1-2-3 Phase) |
| Output Current (A) | 20 – 200 | 20 – 250 | 20 – 300 | 20 – 300 | 20 – 400 | 20 – 200 | 20 – 250 | 20 – 330 |
| Rated Input Power (KVA) | 5.8 | 8.2 | 10.5 | 21 (1-PH) & 12 (2-PH) | 25 (1-PH), 12.7 (2-PH) & 12.7 (3-PH) | 18 (1-Ph) & 10 (2-PH) | 21 (1-Ph) & 12 (2-PH) | 26 (1-Ph), 12.8 (2-PH) & 12.8 (3-PH) |
| IGBT / MOSFET | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT |
| Welding Rod Size can be use | 16 – 3.15 | 1.6 – 3.15 | 1.6 – 4.0 | 1.6 – 4.0 | 1.6 – 5.0 | 1.6 – 3.15 mm | 1.6 – 4.0 mm | 1.6 – 4.0 mm |
| Weight (Kg.) | 4.600 | 4.900 | 5.300 | 7.200 | 8.800 | 5.00 | 5.800 | 7.500 |
| Dimension (mm) | 490 x 210 x 370 | 490 x 210 x 370 | 490 x 210 x 370 | 490 x 210 x 370 | 490 x 210 x 370 | 450 x 210 x 340 | 450 x 210 x 340 | 585 x 260 x 420 |
| Accessories | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder |
| Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp |
| Model | ARC 200 E | ARC 200 S | ARC 200 DT | ARC 200 G | ARC 200 T | ARC 250 T | ARC 300 G | ARC 315 G | ARC 400 G |
| Input Voltage (V) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) |
| Output Current (A) | 20 – 200 | 20 – 200 | 20 – 200 | 20 – 200 | 20 – 200 | 20 – 200 | 20 – 300 | 20 – 315 | 30 – 400 |
| Rated Input Power (KVA) | 5.8 | 5.8 | 5.8 | 6.0 | 6.8 | 10.2 | 10.2 | 10.8 | 13.9 |
| IGBT / MOSFET | IGBT | IGBT | IGBT | IGBT | MOSFET | MOSFET | IGBT | IGBT | IGBT |
| Welding Rod Size can be use | 1.6 – 3.15 | 1.6 – 3.15 | 1.6-3.15 | 1.6 – 315 | 1.6 – 3.15 | 1.6 – 4.0 | 1.6 – 4.0 | 1.6 – 4.0 | 1.6 – 5.0 |
| Weight (Kg.) | 3.500 | 3.600 | 3100 | 4.000 | 5.00 | 5.700 | 8.300 | 11.700 | 13.300 |
| Dimension (mm) | 375 x150 x 300 | 375 x150 x 300 | 290 x140 x 220 | 380 x160 x 320 | 380 x155 x 305 | 380 x155 x 305 | 480 x 210 x 370 | 490 x 210 x 370 | 500 x 245 x 440 |
| Accessories | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder |
| Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp |
| Model | ARC 415 G | ARC 400 ij | ARC MMA 200 T | ARC MMA 250 T | ARC 400 HD | ARC 200 L | ARC 200 DT | ARC 250 L | ARC 200 T |
| Input Voltage (V) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) | 220 V – 415 V ± 15% (1-2 Phase) | 220 V – 415 V ± 15% (1-2 Phase) | 220 V – 415 V ± 15% (1-2-3 Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) | 220 V ± 15% (1-Phase) |
| Output Current (A) | 30 – 415 | 30 – 400 | 20 – 200 | 20 – 250 | 20 – 400 | 20 – 200 | 20 – 200 | 20 – 250 | 20 – 200 |
| Rated Input Power (KVA) | 15.6 | 18.5 | 18 (1-PH) & 10 (2-PH) | 21 (1-PH) & 12 (2-PH) | 37 (1-PH),12.8 (2-PH) & 12.8 (3-PH) | 6.8 | 6.8 | 10.2 | 8.5 |
| IGBT / MOSFET | IGBT | IGBT Module | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT | MOSFET |
| Welding Rod Size can be use | 1.6 – 5.0 | 1.6 – 5.0 | 1.6 – 315 | 1.6 – 4.0 | 1.6 – 5.0 | 1.6 – 3.15 | 1.6 – 3.15 | 1.6 – 4.0 | 1.6 – 3.15 |
| Weight (Kg.) | 19.000 | 23.700 | 5.000 | 5.300 | 10.200 | 5.000 | 3.600 | 5.800 | 6.500 |
| Dimension (mm) | 520 x 275 x 465 | 580 x 290 x 540 | 380 x155 x 305 | 380 x155 x 305 | 485 x 210 x 370 | 400 x 159 x 300 | 305 x 146 x 258 | 400 x 159 x 300 | 400 x 159 x 300 |
| Accessories | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder |
| Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp |
| Model | ARC 250 T | ARC 250 G | ARC 315 G | ARC 400 G | ARC 630 G | ARC MMA 200 T | ARC MMA 250 T | ARC MMA 400 HD |
| Input Voltage (V) | 220 V ± 15% (1-Phase) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) | 415 V ± 15% (3-Phase) | 220-415 V ± 15% (1-2 Phase) | 220-415 V ± 15% (1-2 Phase) | 220-415 V ± 15% (1-2-3 Phase) |
| Output Current (A) | 20 – 250 | 20 – 250 | 20 – 315 | 20 – 400 | 20 – 630 | 20 – 200 | 20 – 250 | 20 – 400 |
| Rated Input Power (KVA) | 10.2 | 8.0 | 10.2 | 15.6 | 25.3 | 18 (1 PH) & 10 (2 PH) | 21(1 PH) & 12 (2 PH) | 37 (1PH), 12.8 (2PH) & 12.8 (3PH) |
| IGBT / MOSFET | MOSFET | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT | IGBT |
| Welding Rod Size can be use | 1.6 – 4.0 | 1.6 – 4.0 | 1.6 – 4.0 | 1.6 -5.0 | 1.6 – 5.0 | 1.6 – 3.15 | 1.6 – 4.0 | 1.6 – 5.0 |
| Weight (Kg.) | 9.100 | 10.800 | 15.900 | 18.800 | 17.700 | 5.700 | 7.800 | 10.800 |
| Dimension (mm) | 450 x 205 x 370 | 428x 219 x354 | 490 x 235 x 425 | 541 x 234 x 413 | 541 x 234 x 413 | 400 x 159 x 300 | 403 x 181 x 324 | 440 x 260 x 330 |
| Accessories | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder | Welding Cable with Holder |
| Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp | Earthing Cable with Clamp |
